Features:

• High sine wave purity with low phase noise and jitter, audio band THD down to 0.05%
• Square waves up to 100MHz with variable duty cycle, edge speeds down to 3ns
• Resolution of up to 15 digits or 1µHz, high stability TCXO timebase
• Two identical channels - independent or linked with coupled and tracking modes
• Inter-channel phase offset of -3600 to 3600 with 0.0010 resolution
• 1mHz to up to 100MHz Pulse generation with 100ps width resolution, <30ps jitter, and independently variable rise/fall times
• Wideband noise generator with up to 100MHz noise bandwidth
• Wide range of standard and arbitrary waveforms built-in
• Arbitrary waveforms of 14-bits / 400MSa/s (TGF4042 & TGF4082) or 16-bits / 800MSa/s (TGF4162 & TGF4242)
• Waveform Manager Plus for Windows, editing software included
• Front USB host socket for waveform storage and file transfers using Flash drives
• Modulation frequencies up to 10MHz internal and 5MHz external
• Gate and Burst modes with internal and external triggering

Specifications:

• No. of channels: 2
• Frequency range: 1µHz to 80MHz
• Frequency resolution: 1µHz, 14 digits
• Max frequency (sine): 80 Mhz
• Max frequency (square/ pulse): 25 Mhz
• Vertical bits / Sample rate: 14 bits / 400Msa/s
• Noise bandwidth: 50 Mhz

The TGF4082 is a funtion generator. The TGF4000 series is the latest function/arbitrary generator series from Aim-TTi offering class-leading performance and unrivalled value for money
