ProductDescription
Third-party network cameras supported
Up to 6 Mega pixels resolution recording
HDMI and VGA output at up to 1920×1080P resolution
16/32-ch network cameras can be connected with 160M incoming bandwidth
Up to 4 SATA interfaces
Support network detection, including network delay, packet loss, etc
ProductSpecification
| Brand | Hikvision |
| Product Code | DS-7732NI-E4 |
| Product Type | Network Video Recorder |
| IP video input | 32-ch |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Outgoing bandwidth | 80Mbps |
| Incoming bandwidth | 160Mbps |
| Remote connection | 128 |
| HDMI/VGA output | 1-ch, resolution: |
| Recording Resolution | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate | Main stream: 50 fps (P) / 60 fps (N) |
| Audio Output | 1-ch, RCA (Linear, 1kΩ) |
| Live view / Playback | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability | 16-ch@4CIF, 12-ch@720P, |
| SATA | 4 SATA interfaces for 2 HDDs 1 DVD-R/W (default), or 4HDDs |
| Capacity | Up to 6TB capacity for each HDD |
| Network Interface | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface | RS-232; RS-485; |
| USB Interface | Front panel: 2 × USB 2.0 |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
| Power Supply | 100~240VAC |
| Consumption(without hard disk and POE) | ≤ 20W |
| Working Temperature | -10 ºC ~ 55 ºC ( 14 ºF~ 131 ºF) |
| Working Humidity | 10 % ~ 90 % |
| Chassis | 19-inch rack-mounted 1.5U chassis |
| Dimensions | 445 × 390 × 70mm |
| Weight | ≤ 4 Kg |
