- Supports 8 IP Cameras and up to 8 MP resolution
- 8 Independent PoE Network Interfaces
- HDMI Output Resolution: 1-ch, 4K (3840 × 2160)/30 Hz, 1920 × 1080p/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
- Incoming Bandwidth: 80 Mbps Outgoing Bandwidth: 80 Mbps
- One Year Warranty and Lifetime Tech Support covered by seller
Video/Audio Input
IP video input: | 8-ch
Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth: | 80Mbps
Outgoing bandwidth: | 80Mbps
Video/Audio Output
HDMI Output: 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
VGA Output: 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Decoding
Live view / Playback: | 8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability: | 8-ch@1080P
Hard Disk
SATA: | 1 SATA interfaces for 1 HDDs
Capacity: | Up to 8TB capacity for each HDD
External Interface
USB Interface: | 2, USB2.0
>
POE
Interface: | 8 independent 10 /100 Mbps PoE Ethernet interfaces
General
Power Supply: | 100 to 200 VAC
Consumption(without hard disk and POE): | ≤ 15 W
Working Temperature: | -10 ºC ~ 55 ºC ( 14 ºF~ 131 ºF)
Working Humidity: | 10 % ~ 90 %
Chassis: | 385 mm chassis
Dimensions: | 385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
Weight(without HDD): | ≤ 3 kg (6.6 lb)
