Brand

CP Plus

Product Type

NVR

Product Model

CP-UNR-4K5644-V2

Processor

Quad-core embedded processor

Operating System

Embedded LINUX

Two-Way Talk

1 Channel Input, 2 Channel Output, RCA

User Interface

GUI

Video Output

2 HDMI, 2 VGA

Video Resolution

HDMI1: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 VGA1: 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 ; HDMI2/VGA2: 1920 × 1080

Video Recording

Maximum 320Mbps

Video Display Split

1st screen: 1/4/8/9/16/25/36/64 , 2nd screen: 1/4/8/9/16

Channel

32 channel

Motion Detection

MD Zones: 396(22×18)

Video Loss

supports

Bandwidth Incoming

320Mbps

Alarm Input

16 Channel

Alarm Output

6 Channel

Smart Phone

iPhone, iPad, Android Phone

Hard Disk

4 SATA III ports, up to 10TB Each, 1 eSATA port

Trigger Events

Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Recording Mode

Manual, Schedule (Regular, MD (Motion Detection) , Alarm, IVS), Stop

Search Mode

Time /Date, Alarm, MD and Exact Search (accurate to second)

Backup Mode

USB Device/Network/eSATA Device

Playback

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Maximum User Account

128 users

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Ethernet

2 RJ-45 Ports (10/100/1000Mbps) Independent or Joint Working

Interface Ports

3 USB Ports (2 Rear USB 3.0, 1 Front USB 2.0), 1 RS232, 1 RS485

Protocols

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search , ONVIF 2.4, SDK, CGI

Power Supply

Single, AC 100~240V, 50/60 Hz

Power Consumption

<16.7W (without HDD)

Working Temperature

-10 ~ 55°C / 10~90%RH / 86~106kpa

Dimension

440mm x 411.2mm x 76mm

Weight

4.3kg (without HDD)

Warranty
