Brand

CP Plus

Model No

CP-UNR-4K4164-V2

Product Type

Network Video Recorder (NVR)

Processor

Quad-core embedded processor

Operating System

Embedded LINUX

Two-way Talk

1 channel Input, 1 channel Output, RCA

User Interface

GUI

Video Output

1 HDMI, 1 VGA

Video Resolution

HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720, VGA: 1920×1080, 1280×1024, 1280×720

Channel

16 channel

Bandwidth Incoming

200

Motion Detection

MD Zones: 396(22×18).

Video Loss

supports

Alarm Input

16 Channel, Low Level Effective, Green Terminal Interface

Alarm Output

4 Channel, NO/NC Programmable, Green Terminal Interface

Smart Phone

iPhone, iPad, Android Phone

Hard Disk

4 SATA ports, up to 24TB

Trigger Events

Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips

Raid Support

No

Recording Mode

Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop

Search Mode

Time/Date, Alarm, MD & Exact search (accurate to second), Smart search

Backup Mode

USB Device/Network

Playback

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom

Max User Account

128 users

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Ethernet

2 RJ-45 Ports

Interface Ports

1 HDMI, 1 VGA, 2 USB(1USB 3.0), 1 RS485, 1 RS232

Protocols

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, IP Search, ONVIF 2.4, SDK, CGI

Redunant Power

No

Power Supply

AC 100~240V, 50/60 Hz

Power Consumption

<13.7W (Without HDD)

Working Temp

-10 ~ 55°C / 10~90%RH / 86~106kpa

Dimension

440mm x 411.1mm x 76mm

Weight

4.7kg (without HDD)

Warranty

As Per Manufacturer Terms And Conditions
