Brand

CP Plus

Model No

CP-UNR-4K2161-V2

Product Type

Network Video Recorder (NVR)

Processor

Dual-core embedded processor

Operating System

Embedded LINUX

IP Camera Input

16 channel

Two-way Talk

1 channel Input, 1 channel Output, RCA

User Interface

GUI

Video Output

1 HDMI, 1 VGA

Video Resolution

1920×1080, 1280×1024, 1280×720, 1024×768

Video Recording

Max 160 Mbps, 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.

Video Display Split

1/4/8/9/16

Channel

16

Bandwidth Incoming

160

Motion Detection

MD Zones: 396(22×18).

Video Loss

Supports

Smart Phone

iPhone, iPad, Android Phone

Hard Disk

1 SATA III ports, up to 6TB

Trigger Events

Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips

Raid Support

No

Recording Mode

Manual, Schedule(Regular(Continuous), MD, Stop

Search Mode

Time/Date, MD & Exact search (accurate to second)

Backup Mode

USB Device / Network

Playback

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom

Max User Account

128 users

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Ethernet

1 RJ-45 port (10/100/1000Mbps)

Interface Ports

1 HDMI, 1 VGA, 2 USB Ports(1 Rear USB2.0, 1 Front USB2.0)

Protocols

HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search, ONVIF 2.4, SDK, CGI

Redunant Power

No

Power Supply

DC12V/2A

Power Consumption

<3W (without HDD)

Working Temp

-10 ~ 55°C / 10~90%RH / 86~106kpa

Dimension

260mm x 224.9mm x 47.6mm

Weight

0.8kg (without HDD)

Warranty

As Per Manufacturer Terms And Conditions
