Product Description
-
Up to 64 channel IP camera input
-
Up to 12MP resolution preview and playback
-
Max 320Mbps incoming bandwidth
-
Instastream/H.265/Smart H.264 /H.264/MJPEG
-
Analytics By Camera: ANPR, People Counting, Tripwire, Intrusion, Heatmap, Missing Abandon Detection, Face Detection, Face Recognition
-
Support 8 SATA HDDs up to 16TB Each, 4 USB Ports (2 USB3.0), 1 eSATA port
-
2 HDMI / 2 VGA simultaneous video output
-
Support Multi-brand network cameras
-
Support RAID 0/1/5/10
-
ONVIF Version 2.4 conformance
-
Mobile Software: iCMOB, gCMOB
-
CMS Software: KVMS Pro
Product Specification
|
Brand |
CP Plus |
|
Product Type |
NVR |
|
Product Model |
CP-UNR-4K564R8-V2 |
|
Processor |
Quad-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Two-way Talk |
1 Channel Input, 2 Channel Output, RCA |
|
User Interface |
GUI |
|
Video Output |
2 HDMI, 2 VGA |
|
Video Resolution |
HDMI1: 3840 × 2160, 1920 × 1080, 1280 × 1024,1280 × 720, 1024 × 768 VGA1: 1920 × 1080 1280 ×1024,1280 × 720, 1024 × 768, HDMI2/VGA2: 1920 × 1080 |
|
Channel |
64 channel |
|
Motion Detection |
MD Zones: 396(22×18). |
|
Bandwidth Incoming |
320 |
|
Video Loss |
supports |
|
Alarm Input |
16 Channel |
|
Alarm Output |
6 Channel |
|
Hard Disk |
8 SATA III ports, up to 16TB each, 1 eSATA port |
|
Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
|
Analytics By Camera |
ANPR, People Counting, Tripwire, Intrusion, Heatmap, Missing Abandon Detection, Face Detection, Face Recognition |
|
Recording Mode |
Manual, Schedule (Regular, MD (Motion Detection) , Alarm, IVS), Stop |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second) |
|
Backup Mode |
USB Device/Network/eSATA Device |
|
Playback |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
|
Max User Account |
128 users |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Ethernet |
2 RJ-45 port (10/100/1000Mbps) |
|
Interface Ports |
4 USB ports (2 Rear USB3.0, 2 Front USB2.0), 1 RS485, 1 RS232 |
|
Protocols |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search, ONVIF 2.4, SDK, CGI |
|
Power Supply |
Single, AC 100~240V, 50/60 Hz |
|
Power Consumption |
<16.7W (without HDD) |
|
Working Temp |
-10 ~ 55°C / 10~90%RH / 86~106kpa |
|
Dimension |
440mm×450.1mm×95mm |
|
Weight |
6.55KG (without HDD) |
|
Warranty |
As Per Manufacturer Terms and Condition |
