Product Details
＋
General Information
Manufacturer
Bytecc
Part Number
BT-PSAPA
Product Type
Add On Card
California Residents
Interface
Ports
1 x SATA
1 x eSATA
1 x eSATA
Technical Information
Data Transfer Rate
1.5 Gb/s
Miscellaneous
Package Contents
PCI SATA Controller Card 1 x Sata cable. 1 x User Manual 1 x Driver CD
Features
SATA host controller chip with 32-bit interfacing
Compliant with SATA 1.0 specification
Supports two independent SATA ports with data transfer rate up to 1.5Gb/s
Built-in 256 bytes FIFO per port for fast read/write operations
Supports microsoft generic IDE operation and intel bus master DMA operations
RAID function optional
Supports RAID function 0 and 1
Adjustable stripe size for RAID 0
Supports co-exist RAID set and Non-RAID HDD
Allow HDDs with different sizes to be configurated in a RAID set
Compliant with SATA 1.0 specification
Supports two independent SATA ports with data transfer rate up to 1.5Gb/s
Built-in 256 bytes FIFO per port for fast read/write operations
Supports microsoft generic IDE operation and intel bus master DMA operations
RAID function optional
Supports RAID function 0 and 1
Adjustable stripe size for RAID 0
Supports co-exist RAID set and Non-RAID HDD
Allow HDDs with different sizes to be configurated in a RAID set
